Single Channel Blood Infusion Warmer

AM-608

Specifications

Temperature setting: 33C – 41C

Power supply: a.c.100~240V/50~60Hz

Power consumption: Max. 120VA

Type of protection against electric shock: Class I

Degree of protection against electric shock: BF Applied part;

Defibrillation-protected

Degree of protection against ingress of liquids: IPX2

Temperature accuracy: ±1.0C

Overheat protection: 42C/43C

Low temperature alarm: 32C

Warming up time: From 20C to 36C approx. 2 min.

Operating mode: Continuous

Dimension (W*D*H): 85×65×175mm

Net Weight: 1.2kg

Warming profile: – length 1400mm

Compatible IV tube: 3.5-5.0mm O.D.

For other options of warming profile, please contact the supplier

Features

High accurate, intelligent microcomputer controlled device for all medical departments:

Blood transfusion / infusion for the patients during operation or after operation

Routine blood transfusion and infusion in the clinical setting

Blood return feeds / dialysis fluids

Enteral/parenteral nutrition and rinsing solutions

Infusion to children and neonates

Normal infusion in cold condition

User friendly interface: Big LED screen showing set temp., actual temp., heating time and fault situation
Heating up to the patient: IV tube is completely wrapped in, no heat loss

Safety features:

Permanent running self-tests

Double independent over-heating protections and automatic cut off

Visual and acoustic alarm for high temperature / low temperature/sensor fault

Advanced dry heating technology: Quick warming up and effective heating

Open system: Accepts standard IV tube, no special disposables needed, economical warming solution without extra consumable costs
